WORLD'S SMALLEST 2,4 GHz VIDEO TRANSMITTER |
Recommended for Government agencies. 10W transmitter with 8 channel receiver, 2 special antennas 9.5 dB gain LOG3/GR, Capacity: 1 video/2 audio channels. Operating frequency: synthesized. This link is Professional and it is recommended for special applications or video surveillance . It is made for long distances - up to 40 miles line-of-sight. Frequency setting is internal.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
Regulated power supplies, antennas and RF cables are included.
SPECIFICATIONS:
| RF OUTPUT POWER: 10W |
CH 1 - CH 4 (2.4 GHz BAND) |
| FREQUENCY: 1700 - 1800 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 40 MILES LINE-OF-SIGHT |
ANTENNA GAIN: 9.5 dB |
| CURRENT CONSUMPTION: 2 A |
|
*Distances up 70 km with the special antennas PH-24L |
| |
|
|
WORLD'S SMALLEST 2,4 GHz VIDEO TRANSMITTER |
Special order, Recommended for Government agencies only. 10W transmitter with receiver, 2 special antennas 9.5 dB gain LOG3/GR, Capacity: 1 video/2 audio channels. Operating frequency: synthesized. This link is Professional synthesized with a digital display inside, and it is recommended for special applications or video surveillance . It is made for long distances - up to 35 miles line-of-sight. Frequency setting is internal. Regulated power supplies, antennas and RF cables are included.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
SPECIFICATIONS:
| BATTERY POWER: 12.6 V |
CHANNELS: ALL CH FROM 1900 - 2100 MHz |
| FREQUENCY: 1900 - 2100 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 35 MILES LINE-OF-SIGHT |
ANTENNA GAIN: 9.5 dB |
| CURRENT CONSUMPTION: 4 A |
|
*Distances up 70 km with the special antennas PH-24L |
| |
|
|
8 CHANNELS MICROWAVE LINK MODEL XLS-2000/HP FOR 2.4 GHz |
10 W transmitter with 8 channels, 8 channel receiver, 2 directional antennas LOG1/GR , Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for excellent sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 35 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
SPECIFICATIONS:
| BATTERY POWER: 12 - 14.4 V |
CHANNELS: 8 |
| FREQUENCY: 2300 - 2500 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 35km LINE-OF-SIGHT |
RF OUTPUT POWER: 10W |
| CURRENT CONSUMPTION: 2 A |
|
*Distances up 70 km with the special antennas PH-24L |
| |
|
|
10 W MICROWAVE LINK MODEL XLD-2000HP WITH DIGITAL DISPLAY FOR 2.4 GHz |
10 W transmitter , receiver, 2 directional antennas LOG1/GR, Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for excellent sensitivity. Operating frequency: synthesized with a digital display inside the unit. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 35 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in aluminumweatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
SPECIFICATIONS:
| BATTERY POWER: 12 - 14.4V |
CHANNELS: ANY |
| FREQUENCY: 2300 - 2500 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 35km LINE-OF-SIGHT |
RF OUTPUT POWER: 5W |
| CURRENT CONSUMPTION: 1600 mA/ 12V |
|
*Distances up 70 km with the special antennas PH-24L |
| |
|
 |
10 W LOW COST MICROWAVE LINK MODEL XLS-5800/HP FOR 5.8 GHz |
XLS-5800/HP is an excellent microwave link for 5.8 GHz. It includes: 10 W transmitter with 8 channels 5.750 MHz - 5.900 MHz, special 8 channels receiver, 2 directional antennas PT-58; Capacity: 1 video and 2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 40 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
SPECIFICATIONS:
| BATTERY POWER:12 V MIN. |
CHANNELS: ALL |
| FREQUENCY: 5600 - 5900 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 40km LINE-OF-SIGHT |
RF OUTPUT POWER: 10W |
| CURRENT CONSUMPTION: 1.8 A |
|
*Distances up 70 km with the special antennas PR-58. |
| |
|
|
10 W LOW COST MICROWAVE LINK MODEL XLD-5800/HP WITH DIGITAL DISPLAY FOR 5.8 GHz |
XLD-5800/HP is an excellent microwave link for 5.8 GHz. It comes with 10 W transmitter with digital display to acces any frequency from 5.600 MHz - 5.900 MHz, special receiver with digital display, 2 directional antennas PT-58 ; Capacity: 1 video/2 audio channels, receiver has built-in low noise amplifier for increased sensitivity. Operating frequency: synthesized. This link is Professional and it is recommended for TV production and Film. It is made for very long distances - up to 40 km line-of-sight. Frequency setting is internal. Both receiver and transmitter are built in weatherproof NEMA enclosures.
Dimensions:
Receiver: 7.5 " X 11 " X 3.5 ".
Transmitter: 7.5 " X 11 " X 3.5 ".
SPECIFICATIONS:
| BATTERY POWER:12 V MIN. |
CHANNELS: ALL |
| FREQUENCY: 5600 - 5900 MHz |
SIZE: 7.5 " X 11 " X 3.5 " |
| RANGE: UP TO 40km LINE-OF-SIGHT |
RF OUTPUT POWER: 10W |
| CURRENT CONSUMPTION: 1.8 A |
|
*Distances up 70 km with the special antennas PR-58. |
| |
|
|
|
